How do I measure for a Custom Grill Cover?

This guide explains how to measure your grill for a custom-fitted Kuvr® Grill Cover, including each required measurement, where to take it, and how to record it accurately. There are 12 measurements to take, labelled A to L.

Kuvr measuring guide diagram for a grill cover, showing measurement points A to L

Important

Provide exact measurements with no extra allowance added. Kuvr® adds a standard tolerance of +25 mm (1 in) to the width and depth for a comfortable fit; no allowance is added to the height. You can measure in centimetres, inches, or metres — you choose your preferred unit when you configure the cover.

Please include photos

Photos of your grill, taken from a few angles alongside your measurements, help us understand the exact shape and get your cover right from the outset. Including a tape measure in shot for scale is ideal.

The measurements

A — Total width

The total width across the whole grill, including both side wings. Measure straight across from the outer edge of one wing to the other, at the widest part.

B — Total depth

The total front-to-back depth of the grill at its deepest point, including any wing shelf that projects forward.

C — Total height

The vertical height from the floor to the highest point of the grill with the lid closed. Measure vertically, keeping the tape straight and plumb.

D — Depth from grill front to wing

The horizontal depth from the front of the grill back to the wing shelf.

E — Depth of wing

The front-to-back depth of the wing shelf.

F — Depth of grill hood

The front-to-back depth of the grill hood (the lid section).

G — Height to top of right wing

The vertical height from the floor to the top of the right-hand wing shelf.

H — Height to top of left wing

The vertical height from the floor to the top of the left-hand wing shelf.

I — Height to top of grill hood handle

The vertical height from the floor to the top of the handle on the grill hood.

J — Width of left wing

The width of the left-hand wing shelf, measured straight across at its widest.

K — Width of grill hood

The width of the central grill hood section, measured straight across at its widest.

L — Width of right wing

The width of the right-hand wing shelf, measured straight across at its widest.

Frequently asked questions

Should I measure with the grill lid open or closed?

Measure with the lid closed, to the highest point of the closed lid. This is the height the cover needs to clear.

Do I include the side shelves or wings?

Yes. Include the side shelves at their widest point. If they fold down, measure both with them up and note that they fold.

Should I measure the grill or my current cover?

Measure the grill itself with any existing cover removed. Measuring over an old cover gives an oversized result.

Ready to order?

Configure your own cover and get an instant quote on our Custom Grill Cover product page.

Downloads

Download the PDF measuring guide
Download the JPG measuring guide
